一、特點：該泵是為輸送含顆粒性較大的漿料或有砂石之類的礦漿而設計的一種低轉速大流道泵，其結構采用軸向進口，徑向出口，確保較大的砂石顆粒進入泵腔后通過開式葉輪立即甩出，不會因停留泵腔內而導致磨損或顆粒卡在葉輪與泵蓋、泵體之間。從而彌補了一般離心泵所不能達到的效果。
二、性能參數
型號 | 流量m3/h | 揚程m | 最高壓力 | 功率 | 轉速rpm | 型號 | 流量m3/h | 揚程m | 最高壓力 | 功率 | 轉速rpm |
YLB50-20-D-K | 15 | 20 | 2 | 5.5 | 1450 | YLB100-40-D-K | 100 | 40 | 4 | 22 | 1450 |
YLB50-30-D-K | 15 | 30 | 3 | 7.5 | 1450 | YLB100-50-D-K | 100 | 50 | 5 | 37 | 1450 |
YLB50-40-D-K | 15 | 40 | 4 | 11 | 1450 | YLB100-60-D-K | 100 | 60 | 6 | 37 | 1450 |
YLB50-45-D-K | 15 | 45 | 4.5 | 11 | 1450 | YLB100-70-D-K | 100 | 70 | 7 | 45 | 1450 |
YLB50-50-D-K | 15 | 50 | 5 | 22 | 1450 | YLB100-80-D-K | 100 | 80 | 8 | 45 | 1450 |
YLB50-60-D-K | 15 | 60 | 6 | 22 | 1450 | YLB100-100-D-K | 100 | 100 | 10 | 110 | 1450 |
YLB50-60-D-K | 15 | 30 | 3 | 5.5 | 960 | YLB125-20-D-K | 100 | 20 | 2 | 11 | 1450 |
YLB50-70-D-K | 15 | 70 | 7 | 18.5 | 1450 | YLB125-30-D-K | 100 | 30 | 3 | 15 | 1450 |
YLB50-80-D-K | 15 | 80 | 8 | 22 | 1450 | YLB125-40-D-K | 100 | 40 | 4 | 18.5 | 1450 |
YLB50-100-D-K | 15 | 100 | 6 | 18.5 | 1450 | YLB125-50-D-K | 150 | 50 | 5 | 37 | 1450 |
YLB65-42-D-K | 30 | 42 | 4.2 | 11 | 1450 | YLB125-60-D-K | 150 | 60 | 6 | 45 | 1450 |
YLB65-50-D-K | 30 | 50 | 5 | 15 | 1450 | YLB125-70-D-K | 150 | 70 | 7 | 55 | 1450 |
YLB65-60-D-K | 30 | 60 | 6 | 18.5 | 1450 | YLB125-80-D-K | 150 | 80 | 8 | 75 | 1450 |
YLB65-70-D-K | 30 | 70 | 7 | 18.5 | 1450 | YLB150-50-D-K | 200 | 50 | 5 | 45 | 1450 |
YLB65-80-D-K | 30 | 80 | 8 | 22 | 1450 | YLB150-60-D-K | 200 | 60 | 6 | 55 | 1450 |
YLB65-100-D-K | 30 | 100 | 10 | 22 | 1450 | YLB150-80-D-K | 200 | 80 | 6 | 55 | 1450 |
YLB80-40-D-K | 50 | 40 | 4 | 22 | 1450 | YLB200-50-D-K | 400 | 50 | 5 | 90 | 1450 |
YLB80-50-D-K | 50 | 50 | 5 | 22 | 1450 | YLB200-60-D-K | 400 | 60 | 6 | 110 | 1450 |
YLB80-60-D-K | 50 | 60 | 6 | 22 | 1450 | YLB200-80-D-K | 400 | 80 | 8 | 132 | 1450 |
YLB80-70-D-K | 50 | 70 | 7 | 30 | 1450 | ||||||
YLB80-80-D-K | 50 | 80 | 8 | 30 | 1450 | ||||||
YLB80-100-D-K | 50 | 100 | 10 | 30 | 1450 | ||||||
YLB80-120-D-K | 50 | 120 | 12 | 30 | 1450 |
